Model NO.
15FW76
15FW76 15" Professional Woofer 8 Ohm
Quantity:

15FW76 15"Professional Woofer 8 Ohm

The Speakers 15FW76 15"midbass driver boasts a blisteringly loud sensitivity rating of 100dB 1W/1m, which combined with its substantial 500 watts RMS power rating makes it capable of generating a lot of output!

FEATURES

  • 380 mm/ 15 in nominal diameter
  • 1000w continuous program power capacity
  • 76 mm/ 3 in vioce coil
  • 100 dB sensitivity

SPECIFICATIONS

Model15FW76
Nominal Diameter380 mm / 15 in
Nominal Impedance8 Ω
Rated Power AES500 W
Continuous Program Power1000 W
Sensitivity @ 1W/1M100 dB
Frequency Range40 - 2000 Hz
Voice Coil Diameter76 mm / 3 in
Voice Coil Winding Depth19 mm / 0.75 in
Magnetic Gap Depth11 mm / 0.43 in

Constructive Characteristics

MagnetFerrite
Basket MaterialAluminium Die-Cast
Voice Coil Winding MaterialCopper
Voice Coil Former MaterialGlass Fibre

Cone Material

Paper
Surround MaterialPolycotton
Dust Dome MaterialPaper

Mounting & Shipping Information

Overall Diameter394 mm (15.51 in)
Bolt Circle Diameter374 mm (14.72 in)
Baffle Cutout Diameter352 mm (13.86 in)
Depth171 mm (6.73 in)
Net Weight9.2 kg / 20.2 lbs
Shipping Weight10.0 kg / 22 lbs
Shipping Box

404x404x186mm(0.030m³)

15.91x15.91x7.32 in
