One for all
With the boxes of the CA-10 you get compact, efficient and economical PA-system, which is suitable for various applications. Use it as a full range PA for small gigs, as a keyboard or e-drum monitor, for installation or as a compact system for DJs. Whatever you are up to: CA-10 always delivers a clear, assertive sound while taking up little space.
Features
- DSP 96kHz frequency 48-Bit Limiter, Comressor, Crossover, and EQ
- 4 Preset modes
- Bluetooth 2.0 stereo
- Protection: Short circuit, over-current, limiter, over temp, soft start
- Controls: Left, Right Volume, sub Volume, DSP Mode, 180 Phase reverse, Bluetooth On/Off, Power On/Off switch
- Indicators: Power, Signal, Limiter, Bluetooth, DSP Mode
General Specifications
| Model | CA-10 | CA-10 |
| Type. | 4'' mid-high range satellite | 10'' Bass reflex subwoofer |
| Freq.Response(-10dB) | 150Hz-16KHz (-10dB) | 40Hz-250Hz (-10dB) |
| Sensitivity 1W@1M | 109dB | 125dB |
| Power | 50 Watts | 300 Watts |
| Nominal Impedance | 16 ohms | 4 ohms |
| Crossover Mode | Passive | Active |
| LF | 4 in. full range woofer, 1 in. VC, 10 OZ, glass fiber corn pape | 10 in. subwoofer, 2 in. VC, 45 OZ |
| HF | / | / |
| Enclosure | ABS | 15mm MDF |
| Appear ance Finish | Texture painting | Texture painting |
Amp type
| Type | ClassD System |
| Output Power / Subwoofer | 300 Watts |
| Output Power / Mid-Hi Top | 2x50 Watts |
| Gain Controls | Top Volume, Bass Volume |
| Line Connectors | XLR/1/4'' |
| Output Connectors | XLR/Male, 2xSpeakon, NL4, 1+/1- |
| Operation Voltage | 100V~120V or 220V~240V |
