Electro Voice MXC-12 Powered Loudspeaker
Quantity:

Electro Voice MXC-12 wooden loudspeaker

The wooden loudspeaker MXC series combines legendary EV sound quality and reliability with the latest technology - all in a compact package suitable for a wide range of sound reinforcement scenarios, including musicians/DJs and live/club/stage monitors installed sound applications. The MXC series features eight models (four powered and four passive), including 12"and 15"two-way models and 15"and 18"subwoofers. It's also good choice for stage monitors.

FEATURES

  • ·QuickSmartDSP features best-in-class processing, wooden loudspeaker MXC's signature single-knob user interface, and intuitive menu navigation via LCD
  • ·High-efficiency 1500 W Class D power amplifier delivers up to 97 dB peak SPL on the MXC-12 via high-sensitivity transducers designed and engineered by MXC
  • ·Intelligent thermal management with a variable-speed fan controlled by multiple onboard sensors, ensuring superior performance and reliability in demanding environmental conditions
  • ·EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage
  • ·Lightweight, compact 15-mm wooden enclosure with internal bracing, durable EVCoat finish, eight M10 threaded mounting points, aluminum pole mounts, and all-metal handles

SPECIFICATIONS

ModelMXC-12 wooden loudspeaker
Type12'' 2-way full range speaker
Freq. Response (-10dB)55Hz-20KHz
Sensitivity 1W@1M97 dB
Power Handling(continuous/program/peak)400/800/1600 watts
Nominal Impedance4 ohms
LF12'' woofer, 3'' VC, 80 OZ
HF1.75'' Titanium
Enclosure15mm MDF
Appearance FinishTexture painting
Shipping Weigh27.50 kg (60.68 lb)
Shipping Box425x415x662 mm (0.117m³)(16.73x16.34x26.06 in)
